Input Control Supply Voltage |
VDC |
3-32 |
Input Control Supply Current |
mA |
4-12 |
Operational Voltage Range |
Vrms |
12-480VAC |
Peak Inverse Voltage |
Vpk |
800Vpk |
Rated Operational Current |
It |
4A |
Minimum Holding Current |
IH |
75 mA |
Rated Peak Withstand Current (t=10ms) |
ITSM |
250A |
Max. Load Integral i2dt(t = 10ms) |
I2t |
312A2S |
Voltage Drop in ON-State |
VTM |
1.2V |
Critical Current Gradient |
di/dt |
≥50A/µs |
Critical Voltage Gradient |
dv/dt |
200 V/µs |
Thermal Resistance Rth DC |
∅ j-c |
1.7 |
Isolation Voltage |
kV |
2.5kV |
Input Control Supply Voltage |
VDC |
3-32 |
Input Control Supply Current |
mA |
4-12 |
Input Max. Impedance |
Ohm |
1.5kΩ |
Continuous Drain Current at 20°C with Heat sink |
Amp |
8 |
Safe Continuous Rating load |
Amp |
4 |
Drain-to-Source Break Down Voltage Vdss(BR) |
VDC |
100 |
Minimum Holding Current |
mA |
3 |
Static Drain-to-Source ON Resistance RDS(ON) |
Ohm |
0.038 |
Power Dissipation Pd @TC- 25°C |
Watt |
33.8 |
Pulsed Drain Current |
IDM |
80 |
Peak Diode Recovery dv/dt |
V/ns |
15 |
Max. OFF State Leakage Current |
mA |
- |
Maximum Junction Temperature Tj(max) |
°C |
150 |
Thermal Resistance Junction to Case Rthjc |
°c/w |
3.7 |
Load Voltage Drop less than at Rated Current |
VDS |
≤0.4 |
Turn ON Delay TimeTd -ON |
mS |
2.4 |
TurnOff Delay TimeTd -OFF |
mS |
2.4 |
Duty Cycle (100%) |
1 | |
Isolation Voltage |
kV |
1.5 |
Square Wave Output |
Hz |
100 |
